1A低噪聲CMOS LDO穩壓器 DIODES AP2115
- 品牌：???DIODES
- 型號：???AP2115
General Description
The AP2115 is CMOS process low dropout linear regulator with enable function, the regulator delivers a guaranteed 1A (min.) continuous load current.
The AP2115 features low power consumption.
The AP2115 is available in 1.2V, 1.8V, 2.5V and 3.3V regulator output, and available in excellent output accuracy ±1.5%, it is also available in an excellent load regulation and line regulation performance.
The AP2115 is available in standard packages of SOIC-8 and SOT-89-5.
Features
? Output Voltage Accuracy: ±1.5%
? Output Current: 1A (Min.)
? Fold-back Short Current Protection: 50mA
? Low Dropout Voltage (3.3V): 450mV (Typ.)@ IOUT=1A
? Stable with 4.7μF Flexible Cap: Ceramic, Tantalum and Aluminum Electrolytic
? Excellent Line Regulation: 0.02%/V (Typ.),0.1%/V (Max.) @ IOUT=30mA
? Excellent Load Regulation: 0.2%/A @IOUT=1mA to 1A
? Low Quiescent Current: 60μA (1.2V/1.8V/2.5V)
? Low Output Noise: 30μVRMS
? PSRR: 68dB @ Freq=1kHz (1.2V/1.8V)
? OTSD Protection
? Operation Temperature Range: -40°C to 85°C
? ESD: MM 400V, HBM 4000V
Applications
? LCD Monitor
? LCD TV
? STB
